SPECIFICATIONS

Brand Name: ARTOU

Origin: Mainland China

Output: Analog Sensor

Theory: Optical Sensor

Model Number: Photoswitch Sensor

Type: Optical-Electronics Sensor

is_customized: Yes

Material: Mixture

Usage: Ray Sensor

ParentNumber: 124625



Description

Net Weight:16g

Working Voltage: 5V/12V

Load Power: AC 250V/10A, DC 30V/10A

ur fixed bolt hole for easy installation



Instructions

1. photoresistors module is most sensitive to ambient light, generally used to detect the brightness of the ambient light.

2. when the ambient light is darker than the threshold value is set, the relay is energized, the common terminal and the normally start is turned on, when external ambient light is brighter than the set threshold value, the relay is switched off, the common terminal and the normally closed end connected.

3. the public side, normally open, normally closed three ports, the equivalent of a dual-control switch, relay coil power, public end and often the beginning of conduction, radio, public end normally closed terminal conduction.
