USB to TTL line (module) / Brush line,

Features:
- Built-in TTL PL-2303HX Serial Controller IC
- Standard USB type A male and TTL 3pin connector
- Simple serial communication
- Super terminal use; commonly used serial debugging tool
- Simple and Easy way to give USB support to your designs
- Available for Linux, Mac, WinCE and Windows (XP, 2003), Vista, Win 7/8
XP system installation process:

Downloaded the driver Click the icon to start the installation, click Next until completed.

Installed correctly; can see in Device Manager - Ports - USB-To-Serial Comm Port (COM3 / COM port you connected the USB interface will display different)



Second, insert the to upgrade small plate, and the system will automatically load the driver for it. Note: TXD and RXD DuPont line shorted to normal test module
Connection:
RX TO TX;
TX TO RX;
GND to GND
Function line Description: Red-VCC, black-GND, Green-TXD, white-RXD
Module use
1, install the driver,

2, restart the computer,

3, the module is plugged into the computer's USB interface, the system will automatically install the driver

4 TXD and RXD connected (ie with a DuPont line a plug in the TXD an interpolation RXD), the module can spontaneously self-closing,

5, open [serial debugger


XP system installation process:

Downloaded the driver Click the icon to start the installation, click Next until completed.

Installed correctly; can see in Device Manager - Ports - USB-To-Serial Comm Port (COM3 / COM port you connected the USB interface will display different)



Second, insert the to upgrade small plate, and the system will automatically load the driver for it. Note: TXD and RXD DuPont line shorted to normal test module.
